Max turning dimension: Ø1100 mm – H600 mm
Spindle: HSK63
Controller: TNC640 – HEIDENHAIN
Probe: BLUM PROBE
Tool preset: Blum laser
Internal cooling: 50 bar
Tool storage: 30 places
Special application: Electrospindle - speed: 0÷60.000 rpm
FEEDS
Maximum feed: 0 - 30.000 mm/1’
Axis acceleration: 2.000 mm/sec2
PRECISION
Turnning table equipped with Schunk precision device “Point Zero”
Positioning: 0.010 mm
Repeatability: 0.005 mm
Rotating axis: ±0.001°
Universal head powered with torque motor with continuous working axis. Completely cooled till 22.000 rpm spindle speed.
Lathing condition: Maximum torque: 4.400 Nm – maximum rotating speed: 600 rpm – Locking torque: 8.000 Nm
